HEULE Combination Drilling Tools

Economical drilling combined with deburring, chamfering or countersinking.

Tool Selector

With HEULE combination drilling tools, you can combine drilling with forward and backwards deburring in a single operation – without stopping the spindle or turning the workpiece. Our combination tools for your CNC machines measurably reduce cycle times and make your series production more efficient.

Schematic of VEX machining: Drilling with simultaneous front and back chamfering in one process step.

VEX

Drilling combined with chamfering forwards and backwards in one single pass in the diameter range from 5.0 to 17.0 mm

VEX

DCC

Solid carbide drilling combined with forward and backward chamfering in a single pass in the diameter range from 4.0 to 10.0 mm

DCC

Module Line

Your drill body combined with our chamfering module for simultaneous machining from bore-Ø 18.0 mm

Module Line

Solutions for your specific application

Your application is not shown? We would be pleased to offer advice and develop a solution tailored to your needs.

Custom development Enquiry form

1 2 3 4

Drilling, deburring and chamfering all at once – how it works

With HEULE’s combination tools, a single tool performs several machining steps. Whilst the drill bit creates the required bore in the workpiece, the integrated chamfer or deburring blade deburrs both sides of the bore edge in the same operation. No tool changes, no turning, no additional process steps: the workpiece comes off the machine ready to use. This not only saves machine time but also reduces the need for manual intervention and thus potential sources of error. The result is consistently high machining quality, making it perfectly suited to series production.

HEULE's combination drilling tools simplify production processes by combining drilling with deburring, chamfering or countersinking.

Machine operator at the control of a CNC machine for setting the machining process

Optimised process times

Execution of several work steps in a single pass – up to 3 functions in one combination tool
No need to rotate the workpiece or stop the spindle
Standard range
Maximum optimisation of process times with customer-specific solutions

VEX combination tool produces a precise bore with a chamfer on both sides

Work reliably

Simple construction
Robust design
Process-reliable functionality

Safe to use

Easily exchangeable drill bits and carbide chamfering blades
Short set-up and non-productive times thanks to simple handling

HEULE VEX combination tool for process-reliable drilling and forward and reverse chamfering

Great variety

Specific tools for different applications

Webseite_Vorschau_Anwendungen_nur Bild16

Wide range of uses

For drilling depths up to 2x bore diameter

Reduction in cycle time

Combining several operations in a single tool measurably reduces the machining time per bore

Cost savings

No tool changes, no re-clamping, fewer tools in circulation

Reducing the risk of errors

Elimination of manual interventions such as re-clamping or tool changes

Lead time gain

An in-house automated process and the elimination of deburring operations carried out externally

Lower machine utilisation

More efficient machining frees up machine capacity for other operations.

Handling

Simple and safe handling during maintenance and blade changes.

1 2 3 4 5 6

The VEX combination tool drills and chamfers the front and back of a bore in a single pass

1 / 2

Brake disc | With several work steps integrated into a single tool for maximum cost efficiency.

More about the brake disc All sample applications

1 / 2

Sprocket | 34% cycle time reduction.

More about the sprocket wheel All sample applications

We are the partner at our customers' side. As an experienced problem solver, HEULE offers a proven standard range as well as custom developments with Swiss precision. Always in focus: Reducing process times and unit costs for our customers.

HEULE employees working on precision tool manufacturing

heule-konstruktion-entgratwerkzeuge-sitzung

More about HEULE

A combination drilling tool is a precision tool for CNC machining that performs drilling and chamfering (or drilling and deburring) in a single operation. HEULE combination drilling tools such as VEX and DCC are specially designed to create both sides chamfers simultaneously as the bore is drilled – without having to turn the workpiece or stop the spindle.

Whilst the drill bit creates the bore, the integrated chamfering or deburring blade performs the deburring. First, the front of the bore is deburred; as the tool retracts, the back side is machined. All this is done automatically in a single operation. The workpiece does not need to be re-clamped, re-positioned or turned.

The main advantage lies in the reduced process times achieved by combining several work steps. As there is no need for tool changes, turning or spindle stops, several process steps are eliminated. This can lead to significant cost savings, particularly in series production, such as for brake discs or crankshafts.

Both the VEX and the DCC are tooling solutions in which HEULE has permanently integrated the chamfering technology into a drill body. In the case of the VEX, this is done with a replaceable drill insert; for the DCC, it is integrated into a solid carbide drill bit. With the Module Line, on the other hand, your existing drill body is supplemented with a chamfering module to maximise time savings and ensure the highest quality.

HEULE’s combination drilling tools are suitable for all common materials used in CNC machining – from aluminium and steel to stainless steel. The carbide chamfering cutters are coated to suit the specific material and can be selected according to the material being machined.

Yes. If the standard tools do not meet the requirements of your specific application, HEULE will work with you to develop a customised combination tool, for example in combination with countersinking. As experienced problem-solvers, we analyse your bore geometry, materials and process requirements and develop a solution that fits perfectly. Please contact us via the enquiry form.
